Luvocom 3F PEEK CF 9676 is a carbon-fiber reinforced PEEK (Polyether Ether Ketone) 3D printer filament. The carbon fibers inside Luvocom 3F PEEK CF 9676 filament significantly improve the stiffness and compressive strength properties of 3D printed parts.

The material unlocks industrial 3D printing applications in various industries, such as aerospace, medical, oil & gas, energy, marine, and automotive. In these industries, it can be used to produce parts that can replace traditional metal and composite parts.

Parts that are 3D printed with Luvocom 3F PEEK CF 9676 filament are suitable for use in applications that will be exposed to short term service temperatures of up to 280ยฐC and continious service temperatures up to 250ยฐC.

Luvocom 3F PEEK CF 9676 filament is suitable for 3D printing dynamically-stressed parts,ย ย chemically- and hydrolytically- resistant parts, non-flammable parts and applications which require inherent flame resistance with low smoke and low toxic gas emissions.

Key features

  • Lehvoss Luvocom 3F PEEK CF 9676 BK inside
  • Suitable for applications with a continuous service temperature of 250ยฐC
  • Short term service temperature of 280ยฐC (during lifetime max. 200h)
  • Heat deflection temperature ofย 280ยฐC
  • Very high strength and stiffness (also in Z-direction)
  • Excellent mechanical properties
  • Non flammable
  • Exceptional chemical resistance properties



Applications

  • Dynamically-stressed parts
  • Highly chemically-resistant parts
  • Hydrolytically- resistant parts
  • Aerospace applications
  • Automotive



The PAEK family

PolyArylEtherKetone (PAEK) is a family of semi-crystalline high performance thermoplastics that are characterized by high mechanical strength and excellent resistance to temperature, chemicals and wear.
The most widely used members of the PAEK thermoplastic family are:

  • PolyEtherEtherKetone (PEEK)
  • PolyEtherKetoneKetone (PEKK)
  • PolyEtherKetoneย (PEK)
  • PolyEtherKetoneEtherKetoneKetoneย (PEKEKK)
  • PolyEtherEtherKetoneKetoneย (PEEKK)



General printing guidelinesย *

Nozzle size:ย โ‰ฅ 0.4mm Layer height:ย โ‰ฅ 0.10mm Experience level:ย Expert
Print temp:ย ยฑ 400 – 450ยฐ C Fan speed:ย 0 – 25% Drying:ย +4 hours at max.110ยฐC
Heat bed:ย โ‰ฅย 120ยฐ C Enclosure needed:ย 90ยฐC heated chamber Adhesion:ย EasyFix Nr. VII

*) Above displayed settings are meant as guidance to find your optimal print settings. These ranges in settings should work for most printers, but please do feel free to experiment outside these parameters if you think it is suitable for your printer. There are a lot of different type of printers, hot-ends and printer offset that it is extremely difficult to give an overall one-size-fits-all setting.

Abrasiveness

Please be aware that LUVOCOM 3F PEEK CF 9676 BKย filaments contain a relatively high concentration of extremely hard carbon fibres, which have an abrasive nature. In general these carbon fibres will accelerate the nozzle-wear of brass nozzles, much faster than unfilled filaments. We recommend to use nozzles from stainless steel or other hardened alloys.

Filament length

ฯ: 1.36 g/cc 0.2 Kg spool 0.5 Kg spool
ร˜ 1.75mm ยฑ 61m ยฑ 153m
ร˜ 2.85mm ยฑ 23m ยฑ 58m



Product export information

HS Code:ย 39169090 Description:ย Monofilament Country of origin:ย the Netherlands



Compliance *

This filament is compliant to below-listed directives and regulations.

  • RoHS directive 2011/65/EC
  • REACH directive 1907/2006/EC

*) This declaration of conformity to directives and regulations is prepared according to our present standard of knowledge and may be amended if new cognitions are available and applies only for the above-described products.

Technical Datasheet:

Safety Datasheet:

LUVOCOM 3F PEEK CF 9676

Luvocom 3F PEEK CF 9676 is one of the highest performing PEEK 3D printer filaments with carbon fiber reinforcement, which 3D prints PEEK parts with improved stiffness and compressive strength.

1.75
2.85
Carbon Reinforced Black
200
500
750

LUVOCOM 3F PEEK CF 9676

Luvocom 3F PEEK CF 9676 is one of the highest performing PEEK 3D printer filaments with carbon fiber reinforcement, which 3D prints PEEK parts with improved stiffness and compressive strength.

1.75
2.85
Carbon Reinforced Black
200
500
750

If a product is out of stock, it is usually replenished within two weeks.
