PEI ULTEM 1010 is an amorphous ultra-performance PEI (Polyether Imide) 3D printer filament. It combines exceptional dimensional stability with good chemical resistance. The material has a glass transition temperature of 217°C. Parts printed with the filament are suitable for use in applications that will be exposed to continuous service temperatures up to 170°C.

PEI ULTEM 1010 is a flame retardant 3D printing filament with low smoke evolution. It meets the UL 94 V-0 and 5VA ratings. The material combine excellent layer bonding, dimensional accuracy, a high impact resistance, durablitity and a high tensile strength into one filament.

Key features

  • Glass transition temperature of 217°C
  • Suitable for applications with a continuous service temperature of 170°C
  • Excellent dimensional stability
  • Long-term hydrolytic stability
  • Excellent mechanical properties
  • Flame retardant with UL 94 V-0 and 5VA ratings
  • Exceptional chemical resistance properties



Applications

  • Electrical applications
  • Chemically-resistant parts
  • Durable parts
  • Aerospace applications
  • Automotive



General printing guidelines *

Nozzle size: ≥ 0.4mm Layer height: ≥ 0.10mm Experience level: Expert
Print temp: ± 360 – 400° C Fan speed: 0 – 25% Drying: +4 hours at max.110°C
Heat bed: ≥ 120° C Enclosure needed: 90°C heated chamber
Adhesion: EasyFix Nr. VII

*) Above displayed settings are meant as guidance to find your optimal print settings. These ranges in settings should work for most printers, but please do feel free to experiment outside these parameters if you think it is suitable for your printer. There are a lot of different type of printers, hot-ends and printer offset that it is extremely difficult to give an overall one-size-fits-all setting.

Filament length

ρ: 1.27 g/cc 0.2 Kg spool 0.5 Kg spool
Ø 1.75mm ± 65m ± 164m
Ø 2.85mm ± 25m ± 62m



Product export information

HS Code: 39169090 Description: Monofilament Country of origin: the Netherlands



Compliance *

This filament is compliant to below-listed directives and regulations.

  • RoHS directive 2011/65/EC
  • REACH directive 1907/2006/EC

*) This declaration of conformity to directives and regulations is prepared according to our present standard of knowledge and may be amended if new cognitions are available and applies only for the above-described products.

Technical Datasheet:

Safety Datasheet:

PEI ULTEM 1010

PEI ULTEM 1010 combines excellent thermal properties, exceptional dimensional stability, inherent flame retardancy and good chemical resistance into a high performance 3D printing filament.

1.75
2.85
Natural
200
500
750

PEI ULTEM 1010

PEI ULTEM 1010 combines excellent thermal properties, exceptional dimensional stability, inherent flame retardancy and good chemical resistance into a high performance 3D printing filament.

1.75
2.85
Natural
200
500
750

If a product is out of stock, it is usually replenished within two weeks.
